Samarium Cobalt Countersunk Disc Magnet - 3/8 in. dia x 3/16 in. thick x 1/8 in. Hole - 4.41lbs Pull
*Measurements have been rounded to the nearest fraction inch - please check the product description for specific measurements.*
High-performance countersunk samarium cobalt (Sm2Co17) magnet available with either pole on the countersunk face. With a maximum operating temperature of 300oC these magnets are perfect for high-temperature applications.
Pack quantity 4: 4 Countersunk magnets
Please fill out the following form to Ask a Question about this product:
Please fill out the following form to Tell a Friend about this product:
Please fill out the form below and we'll get back to you.
Samarium Cobalt Countersunk Disc Magnet - 3/8 in. dia x 3/16 in. thick x 1/8 in. Hole - 4.41lbs Pull
- 10mm diameter x 5mm thick with a 3.2mm diameter countersunk hole for fixing.
- 0.39 in. diameter x 0.2 in. thick with a 0.13 in. diameter countersunk hole for fixing.
- +/-0.1mm (0.0004 in.) tolerance.
- Each magnet can support 1.4kg (3.09lbs) pull vertically from the magnetic face when in flush contact with a mild steel surface.
- Resistant to corrosion and demagnetisation.
- Can be fixed in place with our.
Samarium cobalt is a type of rare-earth magnet that has the ability to withstand and operate in high temperatures, however they are not as powerful as super-strong Neodymium magnets. Because of their high maximum operating temperature they are commonly used in applications such as motors and electric motors, turbo machinery and sensors.
