N42SH Neodymium Disc Magnet - 5/32 in. dia x 5/32 in. thick - 1.11lbs Pull
*Measurements have been rounded to the nearest fraction inch - please check the product description for an accurate measurement.*
High-performance Neodymium (N42SH) cylindrical disc magnets made from high-temperature resistant material. Ideal for manufacturing and engineering in high-temperature applications.
- 4mm diameter x 4mm thick
- 0.16 in. diameter x 0.16 in. thick
- +/-0.004" tolerance
- Each magnet's north and south pole are on opposite 3/19'' diameter faces
- Each magnet can support 1.27lbs pull vertically from the magnetic face when in flush contact with a mild steel surface
- High-temperature grade with a maximum operating temperature of 302 degrees Fahrenheit
- Excellent resistance to demagnetisation
- Coated with three layers of nickel, copper and nickel to reduce corrosion and provide a smooth finish
These high-performance, high-operating temperature Neodymium disc magnets combine the performance of Neodymium with the ability to operate in high temperatures up to 302 degrees Fahrenheit. Because of their resistance to high-temperatures and their resistance to demagnetisation they are the ideal choice for manufacturers in the automotive, aerospace, engineering and food production industries.
